VIO-200/MX200 series touch monitor provides a wide selection of display sizes are available from 12.1” to 23.8” with a format aspect of 4:3 and 16:9, and selected touch type. Featuring a flat surface, IP 65 dust/waterproof front panel, and aluminum die-casting front frame with a rugged body structure, it is rugged and reliable for an industrial environment. It also supports Multi-Mode Display Module (MDM) technology, which allows for easy configuration, upgrade and maintenance.
VIO-200/MX200 series supports both digital and analog signal input via three types of display interface: VGA, HDMI and DisplayPort. Touch screen can be connected with a USB or a COM port. It also has a multi-language OSD function for adjusting the view options of the display. In addition, supporting a wide range of power input from 9 to 48VDC and high reliability, even operating in temperature extremes. Featuring a completely cable-less design and high functionality, VIO-200/MX200 series are ruggedized display systems that can operate in harsh environments and are easy to install and maintain. A built-in overvoltage protection (OVP), overcurrent protection, and reverse protection DC power input make VIO-200/MX200 series a safe system for all industrial applications.
| Display | |
|---|---|
| LCD Size | 17” (4:3) |
| Max. Resolution | 1280 x 1024 (SXGA) |
| Brightness (cd/m2) | 350 / 1000 (Optional) |
| Contrast Ratio | 800:1 |
| LCD Color | 16.7M |
| Pixel Pitch (mm) | 0.264 (H) x 0.264 (V) |
| Viewing Angle (H-V) | 160 / 140 |
| Backlight MTBF | 50000 hrs (LED Backlight) |
| Touch | |
|---|---|
| Resistive 5-wire | VIO-217R/MX200 |
| Projected Capacitive | VIO-217C/MX200 |
| I/O | |
|---|---|
| VGA | 1x VGA Input |
| HDMI | 1x HDMI Input |
| DisplayPort | 1x DisplayPort Input |
| USB 2.0 | 1x USB 2.0 Input |
| COM Port | 1x COM Port Input (Resistive Touch Only) |
| Audio | 1x Audio Input |
| Other Features | |
|---|---|
| Internal Speaker | AMP 10W + 10W |
| OSD | LCD On/Off, Auto, Menu, Up and Down Multi-language |
| Power | |
|---|---|
| Power Supply Voltage | 9~48VDC |
| Power Connector | 3-pin Terminal Block |
| Power Adaptor | Optional AC/DC 12V/5A, 60W |
| Power Protection | OVP (Over Voltage Protection) OCP (Over Current Protection) Reverse Protection |
| Environment | |
|---|---|
| Operating Temp. | -10°C to 60°C |
| Storage Temp. | -20°C to 70°C |
| Relative Humidity | 10%~80% (non-condensing) |
| IP Level | IP 65 Compliant Front Panel |
| Vibration | 1.5 Grms, 5 – 500 Hz, 0.5 hr/axis |
| Shock | 20G, half sine, 11ms |
| Standards / Certification | UL Safety: UL62368-1, 3rd Ed., (cULus) CE, FCC Class A |
| Physical | |
|---|---|
| Front Panel Construction | Die-cast Flat Surface |
| Dimension | 407.5 (W) x 339 (D) x 70.5 (H) mm |
| Weight | 6.3 kg ~ 6.38 kg |
| Mounting | VESA Mounting Holes 75 x 75mm, 100 x 100mm |
- All product specifications and information are subject without notice.
