General description
| Part number | F00V1301110006 |
| Life cycle status | Mature |
| Warranty | Up to 5 years |
Interface
| Ethernet | Fiber port/RJ45 port |
| Total ports number | 1 |
| 10/100TX ports | 1 |
| DC power input | 1 x DC 24V (18-32V) |
| Fiber connector type | Duplex SC for multi-mode |
Features
| Packet transfer mode | Switch/Pure Converter mode |
| Link loss forward | Two-way loss-signature auto forwarding |
Mechanical
| Housing/protection (IP) | IP31/Aluminum |
| Dimension (HxWxD mm) | 70 x 30 x 80 |
| Mounting | DIN Rail |
| Operating temperature | -40~80℃ |
Certification
| Regulatory/approval | CE/FCC |
