Panel PC all-in-one 21.5" IVS-215

Panel PC featuring a 21.5-inch LED backlit display with 1920x1080 resolution and 10-point multi-touch

21.5-inch LED backlit display, 1920x1080 resolution, full viewing angle, with projected capacitive touchscreen supporting 10-point multi-touch
Optional Intel® Elkhart Lake / Alder Lake-U platform
2 or 4 Gigabit Ethernet ports (1000Mbps)
2 x RS232/422/485 (configurable via BIOS)
1 x M.2 Key E 2230 slot (supports Wi-Fi 6)
1 x M.2 Key B 3052/3042 slot (supports 4G/5G modules)
DC 12-36V input, with RVP/SCP/OVP/OCP support

Datasheet Báo giá

Mô tả
Đánh giá (0)

THÔNG SỐ KỸ THUẬT

Configurations	Configurations	Module I	Module II			Module III
Processor	CPU	Intel Celeron® J6412	Intel® CoreTMi3-1215U	Intel® CoreTM i5-1235U	Intel® CoreTM i7-1255U	Supports Intel® Core™ 6th/7th/8th/9th Gen i7/i5/i3 and Pentium®/Celeron® LGA1151 type CPUs. Max.65W TDP
	Core Count/Thread Count	4/4	2P+4E	2P+8E	2P+8E
	Base Frequency	2.00 GHz	1.2 GHz	1.3 GHz	1.7 GHz
	Turbo Frequency	2.60 GHz	4.4 GHz	4.4 GHz	4.7 GHz
	Smart Cache	1.5	10	12	12
	TDP	10W	15W	15W	15W
	Memory	1 x SO-DIMM DDR4-3200, supports up to 16GB	1 x SO-DIMM DDR5-4800, supports up to 32GB			1 x SO-DIMM DDR4-3200, supports up to 16GB
	Storage	1 x M.2 2242/2280 SATA protocol 1 x 7+15Pin SATA3.0 protocol interface	1 x M.2 2242/2280 NVMe protocol 1 x 7+15Pin SATA3.0 protocol interface			1 x M.2 2242/2280 SATA protocol 1 x 7+15Pin SATA3.0 protocol interface
	Network	1x Intel I210AT,1 x Intel I226-v	3 x Intel I226-V, 1 x Intel I210AT Ethernet port (4 Ethernet ports optional with POE motherboard)
	I/O Interfaces	2 x optional RS232/422/485, 4xUSB3.0, 1 x remote switch	2 x optional RS232/422/485, 4xUSB3.2, 2x RS232 (optional), 1x remote switch
	Display Interface	1 * HDMI1.4b	1 x HDMI1.4b，1 x DP1.2
	Expansion	1 x M.2 Key E 2230 slot, expandable for WiFi 6 wireless module; 1 x M.2 Key B 3052/3042 slot, expandable for 4G/5G modules
LCD Screen	Aspect Ratio	16:9
	Resolution	1920×1080
	Luminance	220 cd/m2
	Contrast Ratio	1000:1
	Backlight Life	30000 h
	Angle of View	89 (left), 89 (right), 89 (top), 89 (bottom)
Touch Screen	Type	10-point capacitive screen
	Luminousness	Above 81% (resistive screen > 80%)
	Lifespan	50 million touches (resistive single point 10 million touches)
Power Requirements	Input Voltage	DC 12-36V, supports reverse polarity/short circuit/overvoltage/overcurrent protection
Physical Specifications	Dimensions	532.5X324x71 mm (thickness with motherboards II and III is 79 mm)
	Weight	TBD
Operating System	Operating System	Windows 7 (Motherboard III), Windows 10, Windows 11, Linux
Environment	Operating Temperature（OP）	0 ~ 50 ℃(32~122 ℉)
	Operating Relative Humidity	95% @ 40 ℃ (non-condensing)
	Storage Temperature (NOP)	-20 ~ 60 ℃ (-4 ~ 140 ℉)
	Shock Resistance (OP)	15g 11ms half-sine wave
	Vibration Resistance (OP)	5~500Hz 1Grms
	EMC	CE Class A
	IP Rating	IP65 front panel
